    Composite Film 50packs/Min Sanitary Napkin Packing Machine

    Ask Lasest Price
    Brand Name : JSX
    Model Number : QB-100Y
    Certification : CE/ISO
    Price : negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 10 pcs/month
    Delivery Time : 60-90days
    • Product Details
    • Company Profile

    Composite Film 50packs/Min Sanitary Napkin Packing Machine

    Full servo sanitary napkin packing machine, 40-50 packs/min, composite film


    Description:


    JSX QB-100Y is an auto packing machine for sanitary pads. This machine is driven by full servo motors and controlled by the PLC system of Mitsubishi. And the frame is adopted by the structure with the steel rectangle tube. With technical support, the finished products have neat sealing edges and beautiful appearance. It is packed with different films, especially composite films. Besides, the speed can be 40-50 packs/min. This is one of the popular packing machines in our company.


    Technical Parameter:


    ModelQB-100Y
    Control systemFull servo motor
    Package materialComposite film
    Pack processPre-made bag
    Package sizeL(80-120)*W(30-90)*H(80-180)mm
    Machine dimensionL(6000)*W(950)*H(2000)mm
    Weight1000kg
    Power supply3 phase, 380V+N+PE,±5%,50HZ
    Capacity25KW
    Air consumption0.5m³/min
    Pneumatic0.6Mpa
    CertificationISO/CE
    Speed40-50 packs/min

    Characteristic:


    1. ONE machine can be suitable for various packing materials and different pad specification

    2. Two-phase packing machines to meet most of sanitary pads production lines

    3. Full servo system to ensure the accurate movement for qualified packing capacity

    4. High cost-efficient packing system, finished package with good sealing edges


    Additional service:


    1. Bag material purchase

    2. Upstream and downstream purchase plan

    3. Professional technical train

    4. Perfect packaging machine process
